DC combiner box 12 in and 1 out
CNLonQcom is a Chinese factory specializing in the production of DC combiner box 12 in and 1 out. We provide users with safer, simpler, more aesthetically pleasing, and applicable photovoltaic system products.
Model:LQX F12/1 DC
Send Inquiry
Product Description
The DC combiner box 12 in and 1 out offers features such as dust-proof, anti-reverse, moisture-proof, and intelligent monitoring, with excellent impact resistance and stability.
Please refer to the parameter table and images for detailed specifications.
1.The DC combiner box 12 in and 1 out simplifies the physical wiring between solar panels and inverters.
2.The specification of the DC combiner box 12 in and 1 out
Please refer to the parameter table and images for detailed specifications.
1.The DC combiner box 12 in and 1 out simplifies the physical wiring between solar panels and inverters.
2.The specification of the DC combiner box 12 in and 1 out
TECHNICAL PARAMETERS
| Name | LQX F12/1 DC | ||
|
|
Electric parameter | ||
| System maximum dc voltage | 1000 | 1500 | |
| Maximum input current for each string | 15A | ||
| Maximum input strings |
12 |
||
| Maximum output switch current | 200A | ||
| Number of inverter MPPT | N | ||
| Number of Output strings |
1 |
||
|
|
Lightning protection | ||
| Category of test | II grade protection | ||
| Nominal discharge current | 20kA | ||
| Maximum discharge current | 40kA | ||
| Voltage protection level | 3.6kV | 5.3kV | |
| Maximum continuous operating voltage Uc | 1050V | 1500V | |
| Poles | 3P | ||
| Structure characteristic | Plug-push module | ||
|
|
System | ||
| Protection grade | IP66 | ||
| Output switch | DC isolation switch(standard)/DC circuit breaker(optional) | ||
| SMC4 Waterproof Connectors | Standard | ||
| PV dc fuse | Standard | ||
| PV surge protector | Standard | ||
| Monitoring module | Optional | ||
| Preventing diode | Optional | ||
| Box material | PVC | ||
| Installation method | Wall mounting type | ||
| Operating Temperature | -25℃ ~+55℃ | ||
| Elevation of temperature | 2km | ||
| Permissible relative humidity | 0-95%,noondensation | ||
SCHEMATIC DIAGRAM
DIM ENSIONAL DRAWING(MM)
The details of the DC combiner box 12 in and 1 out
